Features
Thin edge Flat Suction Cup
●Small size, short height
●Available in conductive material
●Available in various shapes: U type, UM type and B type
Selection Guide
HZP3 Series Vacuum Suction Cup
ONLY CUP
HZP3 -02 U N
① ② ③ ④
| ① Series | ② Diameter | ③ Suction cup type | ④ Material |
| HZP3 | 015 - φ1.5mm | U - Flat type | N - NBR |
| 02 - φ2mm | S - Silicone | ||
| 035 - φ3.5mm |
UM - Flat type with tiepiece
|
※ U - PU | |
| 04 - φ4mm | ※ F - Fluororubber | ||
| 06 - φ6mm | GN - Conductive NBR | ||
| 08 - φ8mm | GS - Conductive Silicone | ||
| 10 - φ10mm | |||
| 13 - φ13mm | |||
| 16 - φ16mm |
